Description

    Fried instant noodle processing line is researched and developed by our factory machinery independently so as to meet the market demands, adsorbing advantages of similar equipment at home and abroad, the product is a leading fried instant noodle production equipment at home. It adopts advanced technologies and is of high automation, safety and easy maintenance.And frequency conversion speed regulator, electro-optical tracking system and programmable logic controller to realize synchronized coordination of the whole production line.

    The number of cutting is visible and the weight of one piece of fried instant noodle can be adjusted without having to shut down the machine. The equipment has an automatic frying temperature controlling function.

Instant Noodle Of Production Line

The Equipment Of Production Line

Mixing&Measuring	Dough rolling	Ripening
1.5kw,pump0.75kw,1000L/unit;  140L,with level controller,round tank, pump 0.75kw,	200KG a batch/2 Min. water into a batch	100KG-400KG/10Min
Steaming machine	Cutting& Dividing machine	Frying machine
24m length,water airproof,Main drive 1.5kw, fan 0.37 kw*2units	1.5kw with showering device, cutter 0.9kw*2, 55times/min, speed is adjustable	Main drive 2.2kw, rise&fall 2.2 kw,  cyc pump 7.5 kw,gear pump 2.2 kw, cutter 0.9 kw
Cooling machine	Conveyor	Packing machine
blower 0.37 kw*14 units,exhaust fan 3kw,power provided by frying machine, frame is SS201	Main drive 0.37kw*2,speed adjusted,  SS304 panel	70 to 400mm, Width: 30 to 150mm, Height: 5 to 88mm,  4.3 kW, single phase 220V, 50Hz

Advantages Of Production Line

    This machine adopt the latest technology and grasp the international trend of this kind of product, it has been hot-selling in not only China but also South-east Asia and neighbouring country.
