Product Details:
Payment & Shipping Terms:
|
| Driven Type:: | Electric | Voltage:: | 220V, 50Hz; 220V 60HZ |
|---|---|---|---|
| Name:: | Liquid Filling And Sealing Machine | Speed:: | Adjusted |
| Application:: | Food, Medical | Weight:: | 250KGS |
| High Light: | tomato sauce packaging machine,liquid pouch packaging machine |
||
High Quality Water Fruit Juice Packaging Machine Of Liquid Plastic Bag
Usage:
oil sachet packing machine is mainly used for liquid ice lolly (jelly stick), pure water, milk, soy sauce, vinegar and midecal and chemical liquid quantitative packaging.
Technical characteristics:
1. English and Chinese screen display, operation is simple.
2. PLC computer system, function is more stable, adjustment any parameters not need stop machine.
3. It can stock ten dispose, simple to change variety.
4. Sever motor drawing film, position accurately.
5. Temperature independent control system, precision get to±1°C.
6. Horizontal, vertical temperature control, suitable for various of mix film, PE film packing material.
7. Packing type diversification, pillow sealing, standing type, punching etc.
8. Bag–making, sealing, packing, print date in one operation.
9. Work circumstance quiet, low noise.
Techinical Parameter:
| Model | YB-330Y | YB-150J | YB-300J |
| Filling method | electric valve | piston pump | piston pump |
| Packing speed | 30-80 bags/min | 30-80 bags/min | 10-50bags/mim |
| Packing range | 5-300ml | 5-300ml | 50-1000ml |
| Film width | ≤ 280mm | ≤ 280mm | ≤ 450mm |
| Making bag size |
L: 50-330mm, W: 15-130mm |
L: 50-150mm, W: 15-130mm |
L: 50-300mm, W: 50-210mm |
| Packing accuracy | ≤ ±1%/depends on product) | ≤ ±1%/depends on product) | ≤ ±1%/depends on product) |
| Power | 1.6 KW | 1.6 KW | 1.6 KW |
| Power supply | AC220V, 50/60Hz | AC220V, 50/60Hz | AC220V, 50/60Hz |
| Seal type | 3/4 sides seal, pillow seal | 3/4 sides seal, pillow seal | 3/4 sides seal, pillow seal |
| Net weight | 250kg | 250kg | 250kg |
| Machine dimension | L600 × W790 × H1800mm | L600 × W790 × H1800mm | L800 × W1100 × H1900mm |
Machine Description
• This machine can automatically complete olenoid valve control flow measuring-coding(optional)-bag making-filling-sealing-counting.
• Computer/PLC control system, photoelectric tracking, maximizes the whole machine's control precision. reliability and the intellectualized degree.
• Has fault display system, easy to operate and maintain.
• Machine body and all food touching part are made by stainless steel
• Suitable packing material:PET/AL Plating/PE, PET/PP, BOPP Film, FOIL, Nylon compound film and other materials can be heat sealed.
• this machine can be installed to a color ribbon printer to Print automatically the 1-3 lines code.
Machine computer control:
Machine use computer control, highly stable technology from Japan. The computer system with great stability. Beautiful computer control and screen display! Look beautiful and easy to operate.
