Product Details:
Payment & Shipping Terms:
|
Condition:: | New | Packaging Type:: | Film |
---|---|---|---|
After-sales Service:: | Engineers Available To Service Machinery Overseas | Speed:: | Adjusted |
Application:: | Food, Medical | Power:: | 2.5kw |
High Light: | liquid sachet packaging machine,tomato sauce packaging machine |
Good Quality Vertical Small Liquid Packaging Equipment For Tomato Sauce / juice pouch packing machine
Technical characteristics:
1. English and Chinese screen display, operation is simple.
2. PLC computer system, function is more stable, adjustment any parameters not need stop machine.
3. It can stock ten dispose, simple to change variety.
4. Sever motor drawing film, position accurately.
5. Temperature independent control system, precision get to±1°C.
6. Horizontal, vertical temperature control, suitable for various of mix film, PE film packing material.
7. Packing type diversification, pillow sealing, standing type, punching etc.
8. Bag–making, sealing, packing, print date in one operation.
9. Work circumstance quiet, low noise.
Model | HTL-400Y |
Packing Speed | 30-70 bags/min |
Bag-Making Size | Width 30-150mm, Length 50-200mm |
Filling Range | 5-500ml |
Packing Materials | OPP/CPP PET/PE PET-AL/PE composite material |
Film Width | 80-320mm |
Film thickness | 0.04-0.08mm |
Film Roll Diameter | Max. 320mm |
Power Supply | AC220V/380V 50/60Hz 2.5kw |
Machine Dimensions | (L)1200*(W)900*(H)2150mm |
Machine Weight | 300kgs |
Functions:
1. The food packaging machinery for small business is fully automated operation, it can achieve product packing assembly line work, and improving production efficiency and significantly reduce product cost.
2. The food packaging machinery for small business conforms to the food processing machinery’s sanitation standard. On the machine, the spare part which contacts the material and pouch conforms to thestandard of food sanitation request on material processing, food health and security guarantee.
3. This food packaging machinery for small business can automatically measure, make bags,fill, seal, cut, and print codes. This machine can be used to pack various liquid, like fruit juice,water, tomato sauce, chili sauce, cream, shampoo, peanut butter soy sauce, hand-washing liquid,detergent, suace, etc.
