Product Details:
Payment & Shipping Terms:
|
| Warranty: | 1 Year | Place Of Origin: | Henan, China (Mainland) |
|---|---|---|---|
| Condition: | New Machine | Type: | Noodles Making Machine |
| Material: | 304 Stainless Steel | Voltage: | Available Upon Request |
| Color: | Sliver | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Size: | Can Design According To The Customer's Require | ||
| High Light: | noodle processing line,industrial noodle making machine |
||
Stainless Steel Automatic Instant Noodle Making Machine Processing Line
Description:
Instant noodles process line is with perfect technology, compact structure, original design and stable performance, is developed on the base of advanced products and requirements in the world market.
The noodles Making Machinery are highly effective as well as non stop continuous noodles Making process.The basic operation of Noodles Wheat flour is the main ingredient for making Asian noodles. The dough is compress between Set of two rolls to form a dough sheet. The Enterprises is developed during the sheeting process, contributing to the noodle texture. The sheeted dough is then slitting to produce noodles. The noodles are now ready for sale, or are further process to prolong shelf life, to modify eating characteristics or to facilitate preparation by the consumer. In the preparation of instant fried noodles, the steaming process causes the starch to swell and gelatinize. The addition of alkaline salts (kan sui, a mixture of sodium and potassium carbonates) in some Chinese type noodles gives them a yellow color and a firmer, more elastic texture.
It realizes high automation, convenient operation, low energy and small floor space, that assures all working procedures from feeding flour to finished products can be accomplished once.
With professional team, we can make the most suitable plan as per your requirement and arrange for the installation at your place,even supply the recipe for you. We also have machinery for non-fried instant noodle.
Process flow:
1. Salt Water Mixer: water mixed with additive such as salt, alkali. 2. Brine metering device: measuring the water demand for every pot flour so as to control quantitatively the salt waer volu me from salt water mixer into dough mixer.
3. Dough mixer: flour and water combined and mixed full.
4. Aging machine: dough aging, improve the elasticity of the flour
5. Pressing machine: pressing and cutting
6. Steaming machine: steaming the formed noodles
7. Cutting& Dividing machine: cutting, folding, dividing,, forming the dough pieces and entering boxes, it can form square or circular dough pieces from different molds.
8. Frying machine: dehydrated by frying, fixing the shape of dough pieces, making dough crispy to taste good
9. Cooling machine: lower the temperature of dough pieces to meet the demand of packing.
10. Conveyor: conveying finished instant noodles to each packing line.
11. Packing machine: choosing sauce package packing machine as customers’ request, powder packing
machine, vegetable bag packing machine, pillow type packing machine(instant noodles in bags),captightener(instant noodles in bowls), shrink packing machine(instant noodles in bowls),folding and sealing machine and so on.
Packing machine is optional, excluding standard quotation, choosing as requirement details.
Layout and process flow diagram of noodle production line:
1. Alkali mixing and measuring
2. Flour mixing
3. Ripening
4. Single layer pressing(compound pressing)
5. Continuous pressing
6. Packing room
7. Pole feeding
8. Noodle feeding
9. Cutting
10. Drying
11. Noodle discharging
12. Finished product storage
13. Packing
14. Flour storage
15. Office
16. Host operating position
17. Stairwell
18. Disinfection room
19. Toilets
20. Male locker room
21. Female locker room
22. Spare Room
23. Lifter
Our Service:
1. Seller will send one engineer to Buyer’s company to do installation and trail running and group training.Buyer will burden the visa application fee and the round air tickets and provide the food and accommodation during the time when the engineer stays in Buyer’s company.Also Buyer will pay the engineer about 100 USD per day as subsidy.The installation time would last about 10 days.
2. We are Free insurance for goods, and 24 hours online to solve any problem . Supply you English manual book and technical support , maintain and install video to help you solve the problem, or dispatch worker to your factory.
